DAHUA SF1008L 8-Port Unmanaged Ethernet Switch

The DAHUA SF1008L 8-port unmanaged Ethernet switch delivers instant, reliable 10/100 Mbps connectivity for small to medium CCTV and office networks. All eight ports auto-negotiate speed and duplex with zero configuration required. This fanless metal switch powers IP cameras, NVRs, and computers silently and efficiently. Novatech Technologies supplies genuine DHI-SF1008L units across Kenya with same-day dispatch from Nairobi.

Discover the DAHUA SF1008L 8-Port Unmanaged Ethernet Switch

This plug-and-play switch expands your network the moment you connect it. Auto MDI/MDIX eliminates crossover cables completely. Green Ethernet technology cuts power on idle ports and short cables. Compact metal housing withstands years of continuous operation.

Perfect for Small to Medium CCTV Installations

Installers connect up to eight Dahua IP cameras directly to any non-PoE NVR. Each port delivers full 100 Mbps bandwidth with no bottlenecks. The switch sits neatly beside the recorder without noise or heat issues. Lightning protection keeps cameras safe during storms.

Ideal Office and Home Network Expansion

Small offices add printers, PCs, VoIP phones, and Wi-Fi access points instantly. Home users extend their router to additional rooms without technical help. Desktop or wall-mount design saves valuable desk space.

Detailed Use Cases and Compatibility

The DAHUA SF1008L 8-port unmanaged Ethernet switch works with every standard Ethernet device. It fully complies with IEEE 802.3, 802.3u, and 802.3x standards.

Use Cases in Retail Shops and Restaurants

Boutiques connect POS terminals, receipt printers, and four to eight cameras through one switch. Store-and-forward switching prevents packet loss during busy hours. 2K MAC table handles multiple devices smoothly. For small business network tips, see SmallNetBuilder’s 8-port guide.

This switch pairs perfectly with recorders from Novatech Technologies’ networking category.

Use Cases for Apartments and Gated Homes

Residents extend router ports to the living room, garage, or gate for extra cameras. Zero configuration means anyone can install it in minutes. Low 2 W standby power keeps electricity costs minimal.

Schools and clinics connect teacher laptops, admin PCs, and security cameras without IT staff. Metal casing survives daily handling in busy environments.

Compatibility with Devices and Systems

It supports all Dahua NVRs, IP cameras, PCs, printers, VoIP phones, and access points. Auto-negotiation detects 10/100 Mbps and half/full duplex automatically. Flow control prevents data loss during traffic spikes. Operating temperature spans 0 °C to 40 °C.

Learn about Fast Ethernet standards at IEEE 802.3u specifications.

Add high-quality Cat5e/Cat6 cables from Novatech Technologies’ computer accessories category.

Technical Specifications

Switching Performance

• Ports: 8 × 10/100 Mbps RJ45 (Auto MDI/MDIX)
• Switching Capacity: 1.6 Gbps
• Forwarding Rate: 1.19 Mpps
• MAC Address Table: 2K entries
• Packet Buffer: 1 Mb
• Jumbo Frame: 2 KB

Standards and Features

• Standards: IEEE 802.3, 802.3u, 802.3x Flow Control
• Transmission Method: Store-and-forward
• Green Ethernet: Power saving on idle ports and short cables
• Lightning Protection: 6 kV per port

Physical and Power

• Power Supply: External 5 VDC / 1 A adapter (included)
• Power Consumption: Max 3.5 W
• Operating Temperature: 0 °C to 40 °C
• Dimensions: 130 mm × 85 mm × 26 mm
• Housing: Metal
• Weight: 0.28 kg

View the complete Dahua switch series at Dahua Transmission & Switches page.

Why Choose Novatech Technologies for Your Network Switch

Novatech Technologies stocks only authentic DHI-SF1008L switches in Kenya. We guarantee same-day dispatch and delivery to every county. Secure payments via M-Pesa or cash on delivery protect every order. Our team offers free network layout advice.

Every switch carries a three-year warranty with advance replacement. Dead-on-arrival units qualify for one-day returns. Lifetime phone support is always free. Visit Novatech Technologies’ homepage for total confidence.

Complete your installation with cables and connectors from Novatech Technologies’ computer accessories category.
