Hikvision IDS-7216HQHI-M1/XT DVR

Hikvision IDS-7216HQHI-M1/XT DVR is a 16-channel 1U AcuSense recorder for intelligent video surveillance. This model supports hybrid analog and IP inputs. Moreover, Hikvision IDS-7216HQHI-M1/XT DVR uses H.265 compression for efficient storage savings. As a result, it provides deep learning-based Motion Detection 2.0, perimeter protection, and facial recognition, ideal for medium to large security in Kenyan retail, offices, warehouses, schools, and commercial sites.

Detailed Use Cases and Compatibility

Retail and Business Monitoring

Retail chains use Hikvision IDS-7216HQHI-M1/XT DVR to cover aisles, entrances, cash areas, stock rooms, and parking lots with precise alerts. Offices monitor lobbies, corridors, meeting rooms, and perimeters across floors. Clinics secure waiting zones and service points reliably.

Warehouse and Educational Applications

Warehouses track loading bays, inventory aisles, gates, and access control. Schools protect classrooms, hallways, playgrounds, and entry areas. Therefore, Hikvision IDS-7216HQHI-M1/XT DVR suits expanding medium-scale security requirements.

Camera Connectivity and Upgrades

Hikvision IDS-7216HQHI-M1/XT DVR features 16 analog BNC inputs with coaxitron support. It handles HDTVI, AHD, HDCVI, and CVBS formats up to 3K Lite/5MP Lite/1080p Lite. As a result, analog upgrades proceed without major rewiring. IP mode expands to up to 24 channels (default 8-ch, enhanced), each up to 6 MP resolution. Hybrid setups combine analog and IP cameras for flexible growth.

AcuSense Advanced Intelligence

AcuSense enables Motion Detection 2.0 on analog channels, classifying humans and vehicles to reduce false alarms from environmental factors. Perimeter protection supports line crossing and intrusion detection. Facial recognition offers picture comparison, capture, and search with multiple libraries. Audio over coaxial allows two-way talk.

Remote Access and Display Integration

Remote viewing via Hik-Connect app provides live feeds and playback on mobiles or PCs. Multiple connections maintain smooth performance. HDMI and VGA outputs connect local displays. Browse compatible screens in our monitors category. Manage remotely with devices from our laptops category.

Technical Specifications

Video and Audio Inputs

Analog Video Input: 16-ch BNC (1.0 Vp-p, 75 Ω), coaxitron support Supported Formats: HDTVI/AHD/HDCVI up to 3K Lite/5MP Lite/1080p Lite, CVBS (PAL/NTSC) IP Video Input: 8-ch default (up to 24-ch enhanced), up to 6 MP Supported Codecs: H.265+/H.265/H.264+/H.264 Audio Input: 1-ch RCA + coaxial (16-ch from cameras) Audio Output: 1-ch RCA Two-Way Audio: Supported

Recording and Compression

Video Compression: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 Encoding Resolution: 3K Lite/5 MP Lite/1080p Lite/720p Lite/WD1/4CIF/CIF Frame Rate: Main stream up to 12 fps (3K Lite), 15 fps (1080p Lite) Video Bitrate: 32 Kbps to 6 Mbps (configurable) Audio Compression: G.711u Audio Bitrate: 64 Kbps

Display, Storage and Playback

HDMI Output: 1-ch, up to 1920×1080/60Hz (supports higher in some modes) VGA Output: 1-ch, matching resolutions Simultaneous Output: HDMI/VGA active together Storage: 1 × SATA interface, up to 10 TB capacity Synchronous Playback: Up to 16 channels Search: Smart search by human/vehicle, face, event, motion

Network and General

Incoming Bandwidth: Up to 80 Mbps Network Interface: 1 × RJ45 10/100 Mbps self-adaptive Protocols: TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP, HTTPS Power Supply: 12 VDC Consumption: ≤10 W (without HDD) Operating Temperature: -10°C to 55°C Humidity: 10% to 90% Dimensions: Approx. 260 × 236 × 48 mm Weight: ≤1.5 kg (without HDD)

Hikvision IDS-7216HQHI-M1/XT DVR supports coaxial transmission up to 1200 m. Furthermore, AcuSense enhances detection precision for practical use.

Discover AcuSense features on the official Hikvision website. Additionally, learn H.265 compression benefits from Wikipedia High Efficiency Video Coding. For display compatibility, refer to the HP official site.
