Hikvision DS-K1T808MFWX(O-STD) Pro Fingerprint Terminal

Hikvision DS-K1T808MFWX(O-STD) Pro fingerprint terminal delivers professional-grade biometric access control and time attendance in a compact, wall-mountable design. This advanced terminal combines high-accuracy optical fingerprint recognition with MIFARE card reading and password authentication. It features a large 5-inch touchscreen and robust deep-learning algorithms for fast, reliable identification. Additionally, it supports anti-spoofing and multi-mode verification. Therefore, it suits high-security environments such as offices, factories, schools, and government facilities. Moreover, its durable construction and intuitive interface ensure long-term performance and user satisfaction.

Use Cases and Compatibility

Hikvision DS-K1T808MFWX(O-STD) Pro fingerprint terminal performs excellently in demanding access control and attendance applications. For example, corporate offices use it to secure main entrances, executive areas, and server rooms while accurately tracking employee attendance. Similarly, manufacturing plants deploy it for production floor access and shift-based time recording.

Furthermore, educational institutions apply it to control entry to administrative buildings, computer labs, and staff rooms while monitoring lecturer and administrative attendance. In addition, healthcare facilities secure restricted zones such as pharmacies, record rooms, and staff areas with contactless, fast verification. Meanwhile, commercial complexes and public institutions benefit from its multi-biometric capabilities for visitor management, employee tracking, and compliance reporting. Consequently, it meets the requirements of organizations needing high-security, auditable access control combined with precise time attendance data.

The terminal supports multiple authentication methods: fingerprint, MIFARE card, password, and combinations. It uses advanced optical fingerprint technology with anti-spoofing features to prevent fake fingerprints. The built-in MIFARE reader supports standard 13.56 MHz contactless cards. Capacity includes up to 10,000 fingerprints, 10,000 cards, and 100,000 event records. Recognition speed reaches less than 1 second for fingerprints.

Communication occurs via TCP/IP and RS-485 interfaces. The device connects directly to electric locks, exit buttons, door sensors, alarms, and Wiegand controllers. It supports anti-passback, multi-door interlocking, first-card unlocking, super password, and duress alarm functions. For centralized management, integrate with Hikvision iVMS-4200, HikCentral Professional, or third-party access control platforms. Remote user enrollment, log review, and real-time monitoring are fully supported. Pair with professional displays from our monitors category. Explore complete security solutions at Novatech Technologies.

Technical Specifications

Display and Interface

• Display: 5-inch LCD touchscreen
• Resolution: 480 × 854
• Operation: Capacitive touch + physical buttons
• Audio: Built-in loudspeaker and buzzer

Capacity

• Fingerprint Capacity: 10,000 templates
• Card Capacity: 10,000 cards
• Event Capacity: 100,000 records

Recognition Performance

• Fingerprint Technology: Optical sensor with anti-spoofing
• Recognition Speed: ≤ 1 second
• Card Reading: MIFARE 13.56 MHz
• Card Reading Distance: 1–3 cm

Communication

• Network Interface: 10/100 Mbps self-adaptive Ethernet (TCP/IP)
• Additional: RS-485, Wiegand, USB

Interfaces

• Lock Control Output: 1 (relay)
• Exit Button Input: 1
• Door Contact Input: 1
• Alarm Input/Output: 1/1
• Wiegand Interface: 1 (26/34-bit)
• Tamper Alarm: Supported

General

• Power Supply: 12 VDC
• Power Consumption: ≤ 10 W
• Operating Temperature: -10 °C to +50 °C
• Operating Humidity: 10 % to 90 % (non-condensing)
• Dimensions (W × H × D): Approx. 205 mm × 76.5 mm × 37 mm
• Weight: Approx. 0.6 kg
• Installation: Wall mounting
