Hikvision DS-K4DC105(O-NEU) Door Closer

Hikvision DS-K4DC105(O-NEU) Door Closer controls medium to heavy doors with smooth, adjustable hydraulic action. This heavy-duty door closer suits demanding Kenyan commercial, institutional, and public applications. Moreover, it features EN4–EN6 adjustable force and robust backcheck. Therefore, Hikvision DS-K4DC105(O-NEU) delivers reliable, quiet closure while protecting doors and frames.

Versatile Use Cases and Compatibility

High-Traffic Commercial and Retail

Shopping malls and large retail stores mount Hikvision DS-K4DC105(O-NEU) on main entrances, fire-rated doors, and service corridors. The strong closing force handles heavy traffic doors effectively. Adjustable latching ensures secure final closure. Retailers reduce noise complaints and energy loss from open doors. It integrates with access-controlled entrances seamlessly.

Educational Campuses and Lecture Halls

Universities and colleges install Hikvision DS-K4DC105(O-NEU) on auditorium doors, lecture hall entrances, and library main doors. The backcheck prevents doors from swinging into walls or students. Adjustable speed suits varying usage patterns. Institutions comply with fire safety and accessibility standards. The closer withstands thousands of daily cycles.

Healthcare Hospitals and Waiting Areas

Hospitals use Hikvision DS-K4DC105(O-NEU) on ward double doors, operating theatre entrances, and public corridors. The quiet operation minimizes disturbance to patients. The lock supports fire-rated door compliance. Facilities maintain hygiene with controlled closing. It handles frequent use in high-traffic medical environments.

Government Offices and Public Buildings

Government buildings secure meeting rooms, public counters, and archive areas with Hikvision DS-K4DC105(O-NEU). The heavy-duty force ensures doors close securely after use. Adjustable settings suit different door weights. Public facilities meet building code requirements. The closer enhances overall building safety and energy efficiency.

Industrial Facilities and Warehouses

Factories and warehouses apply Hikvision DS-K4DC105(O-NEU) to production area doors, loading bay entrances, and office partitions. The robust construction resists dust and impacts. Adjustable backcheck protects equipment and walls. Industrial sites maintain secure closure in high-activity zones. It performs reliably in Kenya’s variable industrial conditions.

The door closer mounts via regular, parallel arm, or top-jamb configurations. It fits doors up to 1250 mm wide and 120 kg weight. Compatibility with fire-rated doors meets international safety standards. Installation uses standard templates and hardware. Hikvision DS-K4DC105(O-NEU) complements electric locks and access controllers effectively.

Technical Specifications

Performance Parameters

Closing Force: EN4–EN6 adjustable (suitable for doors 80–120 kg) Max. Door Width: 1250 mm Max. Door Weight: 120 kg Closing Speed: Adjustable 180°–15° Latching Speed: Adjustable 15°–0° Backcheck: Adjustable (strong backcheck for heavy doors) Hold-Open: Optional (not included in standard model)

Mechanical and Hydraulic

Type: Rack and pinion hydraulic door closer Arm Type: Regular (standard), parallel arm, top jamb (optional) Mounting: Push side, pull side, or parallel arm Material: Aluminum alloy body with forged steel arm Finish: Silver (standard), optional black or bronze Certifications: EN 1154 compliant

Physical and Environmental

Dimensions: Approx. 280 mm × 70 mm × 55 mm (body) Weight: Approx. 3.5 kg Operating Temperature: -30 °C to 60 °C Operating Humidity: 0% to 95% non-condensing Durability: Tested for over 500,000 cycles

Installation Features

Mounting Hardware: Included screws, templates, and brackets Adjustment: Independent valves for closing speed, latching speed, backcheck Arm Length: Adjustable for precise alignment Door Compatibility: Left-hand or right-hand opening doors

Why Trust Novatech Technologies

Novatech Technologies stands as a trusted Nairobi-based IT specialist. First, they supply genuine Hikvision products consistently. Second, every purchase includes official manufacturer warranty protection. Moreover, expert support assists with installation and technical issues. In addition, fast nationwide delivery reaches all Kenyan regions efficiently. Therefore, customers rely on Novatech for quality equipment and dependable service. Visit Novatech Technologies for more solutions. Explore networking options for integrated systems. Pair with monitors for effective control rooms.

Advanced Technology Highlights

The rack-and-pinion hydraulic mechanism delivers powerful, consistent closing force. Adjustable valves allow precise tuning of speed and latching for heavy doors. Hikvision DS-K4DC105(O-NEU) prevents slamming while ensuring secure final closure.

Strong backcheck function stops doors before hitting walls or obstacles. Adjustable backcheck suits high-traffic and heavy-door applications. This protects frames and reduces repair costs significantly.

Durable aluminum body with forged steel arm withstands extreme use. Tested for over 500,000 cycles, it guarantees long service life. The closer performs reliably in Kenya’s demanding environments.
