Hikvision LAS60-57CN-RJ45 60W PoE Injector

Hikvision LAS60-57CN-RJ45 60W PoE Injector supplies high-power PoE to demanding network devices. This midspan injector adds power over Ethernet easily. It supports advanced cameras and PTZ units without dedicated PoE switches.

High-Power Delivery of Hikvision LAS60-57CN-RJ45 60W PoE Injector

The injector outputs up to 60 W through a single Gigabit port. It delivers stable voltage in the 54 V to 57 V range.

IEEE 802.3at compliance ensures compatibility with PoE+ devices. It also supports legacy and pre-standard equipment.

Gigabit speeds pass through without bottlenecks. Data rates reach 10/100/1000 Mbps seamlessly.

Built-in protections guard against overloads and short circuits. Surge protection adds extra reliability.

LED indicators show power and PoE status clearly. Green lights confirm normal operation.

RoHS compliance meets environmental standards. The design prioritizes long-term safety.

For PoE technology standards overview, refer to IEEE 802.3at.

Versatile Use Cases for Hikvision LAS60-57CN-RJ45 60W PoE Injector

This injector fits various surveillance and networking needs. It powers high-consumption devices effectively.

Advanced Camera Installations

Power PTZ cameras requiring 60 W for heaters or motors. It suits outdoor models in cold climates.

Install in locations without PoE switches nearby. Run a single Cat5e/Cat6 cable for data and power.

Use with Hikvision Pro series PTZ units. It provides Hi-PoE support for demanding features.

Network Expansion and Upgrades

Add PoE capability to existing non-PoE switches. Inject power mid-span without network changes.

Support wireless access points or VoIP phones in offices. The 60 W capacity handles multiple low-power devices.

Deploy in warehouses or campuses for extended reach. Explore more networking solutions.

Temporary or Remote Setups

Use for field testing or demo systems. Portable design allows quick connections.

Power IP intercoms or access control devices. It ensures stable operation in remote locations.

Combine with long cable runs for perimeter monitoring. The injector maintains performance over distance.

Seamless Compatibility of Hikvision LAS60-57CN-RJ45 60W PoE Injector

This midspan works with standard Ethernet infrastructure. Two RJ45 ports handle data in and PoE out.

It connects between switch and powered device effortlessly. No configuration is required.

Compatible with Hikvision IP cameras, PTZ models, and other IEEE 802.3af/at gear. It powers devices up to 60 W.

Gigabit ports support modern high-bandwidth applications. It passes full-speed data without degradation.

Wide AC input range adapts to various power sources. It operates reliably in Kenya’s electrical environment.

For Hikvision accessory integration details, visit Hikvision intrusion products.

Technical Specifications of Hikvision LAS60-57CN-RJ45 60W PoE Injector

Key specifications highlight its robust capabilities.

• Model: LAS60-57CN-RJ45
• Input Voltage: 90-264 V AC (100-240 V typical), 50/60 Hz
• Input Current: Maximum 2 A
• Output Voltage Range: 54 V to 57 V DC
• Output Power: 60 W maximum
• Output Current: Up to 1.1 A (approximate)
• PoE Standard: IEEE 802.3af/at compliant, supports legacy devices
• Ports: 2 × 10/100/1000 Mbps RJ45 (1 Data In, 1 PoE/Data Out)
• Data Rates: 10/100/1000 Mbps pass-through
• Protections: Over current, short circuit, surge protection
• LED Indicators: Power and PoE status
• Operating Temperature: -20 °C to +60 °C
• Operating Humidity: 5% to 90% (non-condensing)
• Dimensions: Approximately 185 mm × 70.8 mm × 37 mm
• Weight: Approximately 473 g
• Certifications: RoHS, CE, WEEE compliant
• Additional Features: MTBF ≥ 1,000,000 hours, high efficiency

These details align with Hikvision and supplier documentation.
