Siemon RIC-F-SC6-01 6-Fiber SC Adapter Plate

The Siemon RIC-F-SC6-01 6-fiber SC adapter plate ensures reliable fiber optic connections for high-performance networks. This flat Quick-Pack design simplifies installations in various enclosures. It delivers efficiency and precision for modern cabling needs.

Detailed Use Cases and Compatibility

This adapter plate thrives in diverse network environments. IT professionals use it for structured cabling in data centers. Telecom providers deploy it for scalable fiber solutions.

Data Center Applications

In data centers, it supports high-density server connections. The plate handles multimode fibers for links up to 550 meters. Single-mode compatibility extends to long-range setups. It mounts easily in rack enclosures for space efficiency. For more networking solutions, visit Novatech’s networking category.

Enterprise Network Integration

Businesses install it in office wiring closets for seamless connectivity. It links switches to workstations with minimal signal loss. The plate supports OM3/OM4 and OS2 cables for flexibility. It integrates with Siemon’s RIC3 and SWIC3 systems for quick upgrades.

Telecom and FTTH Deployments

Service providers use it for FTTH terminations in outdoor cabinets. Its durable housing withstands harsh conditions. Pair it with SC patch cords for rapid field installations. For fiber standards, refer to TIA/EIA-568-C from the TIA website.

Technical Specifications

Adapter and Fiber Specifications

• Fiber Capacity: 6 fibers (3 SC duplex connectors)
• Connector Type: SC (Subscriber Connector)
• Adapter Material: Phosphor bronze sleeve
• Fiber Modes: Multimode (OM3/OM4), single-mode (OS2)
• Design: Flat Quick-Pack with single-finger latch
• Color: Black

Mounting and Enclosure Compatibility

• Compatible Enclosures: RIC3 Rack Mount, SWIC3 Wall Mount, FCP3 Panel
• Housing Material: High-strength black polymer
• Mounting Type: Snap-in for tool-free installation
• Dimensions: 4.4 x 1.3 inches (standard 1U size)
• Operating Temperature: -10°C to 60°C
• Weight: Lightweight at 0.1 lbs per plate

Performance and Standards

• Insertion Loss: <0.2 dB typical
• Return Loss: >50 dB (multimode), >60 dB (single-mode)
• Durability: Minimum 500 mating cycles
• Compliance: RoHS, UL-listed components
• Packaging: 12 plates per pack

The phosphor bronze sleeve ensures low signal attenuation. This design maintains performance over extended use. Learn more about fiber connectors at IEC 61754 standards.

Why Choose Novatech for Your Siemon RIC-F-SC6-01 6-Fiber SC Adapter Plate

Novatech Technologies offers trusted quality for networking solutions. We provide a two-year warranty on this adapter plate. Our support team delivers expert guidance via phone, email, or chat. Customers enjoy fast, secure delivery across Kenya.

Returns are hassle-free for unopened units within 30 days. Extended warranties are available for added protection. Shop confidently at Novatech Technologies.

Complementary Products for Enhanced Networking

Complete your setup with matching fiber enclosures. Patch cords and panels streamline cabling projects. Pair with high-quality cables for optimal performance. Explore computer accessories for additional tools. For enclosure specifications, visit Siemon’s fiber enclosure guide.
