TP-Link TG-3468 Gigabit PCI Express Network Adapter

TP-Link Gigabit PCI Express Network Adapter Full Technical Specs:

Hardware Specifications:

• Interface: PCI Express
• Standards and Protocols: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
• Port: 1 x 10/100/1000Mbps RJ45 Ethernet Port
• LED Indicator: 1000Mbps Link/Act, 10/100Mbps Link/Act, Duplex

Network Media:

• 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
• 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
• 1000BASE-T: UTP category 5e, 6 cable (maximum 100m)

Performance:

• Data Transfer Rates:
  • Ethernet: 10Mbps (half duplex), 20Mbps (full duplex)
  • Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex)
  • Gigabit Ethernet: 2000Mbps (full duplex)
• Supported Network Operating Systems: Windows 10/8.1/8/7/XP (32/64bit), Linux

Software Features:

• Advanced Features: Supports IEEE 802.1p Priority Queuing, Wake-on-LAN
• Auto-Negotiation: 10/100/1000Mbps

Other Specifications:

• Certification: CE, FCC, RoHS
• Dimensions (W x D x H): 4.8 x 3.1 x 0.8 inches (120.8 x 78.5 x 21.5 mm)
• Environment:
  • Operating Temperature: 0°C to 40°C (32°F to 104°F)
  • Storage Temperature: -40°C to 70°C (-40°F to 158°F)
  • Operating Humidity: 10% to 90% non-condensing
  • Storage Humidity: 5% to 90% non-condensing
