Hikvision RG59 Cable With Power 100M

Discover the Hikvision RG59 Cable With Power 100M, a versatile coaxial solution for integrated video and power transmission over long distances. This 100-meter RG59 cable with power conductors enables reliable CCTV setups, combining BNC video signals with DC power in a single run for streamlined installations.

Detailed Use Cases and Compatibility

Surveillance System Extensions

Extend analog cameras to DVRs in large properties with this dual-purpose cable. It delivers clear video feeds alongside stable 12V DC power without signal boosters. Compatible with Hikvision analog HD-TVI cameras. Security teams monitor entrances and perimeters effectively from central control rooms.

The integrated power pair simplifies wiring in retail stores or warehouses. It supports runs up to 100 meters without voltage drops. Installers reduce labor by pulling one cable instead of two. Operators maintain 24/7 surveillance with minimal maintenance.

For CCTV deployment strategies, explore Security Industry Association.

This cable enhances our networking category for hybrid systems.

Residential Security Networks

Wire outdoor cameras around homes using this robust cable for video and power delivery. It connects bullet cameras to NVRs in garages or attics seamlessly. Works with Hikvision DS-2CE series models. Homeowners view live feeds on mobile apps without interference.

The PVC jacket protects against moisture in garden installations. It accommodates baluns for twisted-pair conversions indoors. Families secure backyards and driveways affordably. Users integrate it with smart doorbells for comprehensive coverage.

Browse our computer accessories category for connectors.

Commercial Building Perimeters

Install this cable along fences for boundary detection in office complexes. It transmits PTZ camera signals and powers pan-tilt functions over distances. Pairs with Hikvision Turbo HD recorders. Facility managers deter intrusions with high-resolution alerts.

The 95% braid shielding minimizes RF noise from urban environments. It fits conduit for code-compliant runs between floors. Businesses scale systems as properties expand. Security personnel respond faster to incidents.

Review video transmission standards at International Electrotechnical Commission.

Temporary Event Surveillance

Deploy this cable for pop-up monitoring at markets or concerts. It links portable cameras to mobile DVRs for event coverage. Compatible with Hikvision value series. Organizers ensure crowd safety with temporary setups.

The 100-meter spool allows flexible routing around stages. It withstands light vehicle traffic when buried shallowly. Teams dismantle and reuse for multiple venues. Events proceed securely with proven reliability.

Technical Specifications

Cable Structure and Materials

This RG59 cable features a solid bare copper center conductor at 20 AWG for low-loss video signals up to 100 MHz. Foam polyethylene dielectric provides velocity factor of 82% for sharp images. Aluminum-mylar foil and 95% tinned copper braid deliver 100 dB shielding effectiveness. The outer PVC jacket measures 6.1 mm in diameter for durability.

Two 18 AWG copper power conductors run parallel for DC delivery. Overall construction includes ripcord for easy stripping. The black sheath resists sunlight degradation outdoors. Compliance with UL 444 ensures safe handling in bundles.

Consult coaxial specs at Society of Cable Telecommunications Engineers.

Explore our desktops category for recording stations.

Signal and Power Performance

It supports NTSC/PAL video with attenuation under 15 dB at 5 MHz over 100 meters. Power handling reaches 300W at 12V DC for multiple cameras. Capacitance limits to 52 pF/m for impedance matching at 75 ohms. Operating temperature ranges from -20°C to 75°C for versatile climates.

Velocity of propagation enables sync pulse stability in long hauls. Return loss exceeds 20 dB for clean terminations. The power pair drops under 2V at full load. These traits guarantee flicker-free displays in analog systems.

Installation and Handling Guidelines

Minimum bend radius sets at 10x diameter to avoid kinking the coax. Tensile strength allows 50 pounds pull tension during deployment. Supplied on 100-meter wooden drums for tangle-free payout. It meets CMR ratings for vertical risers in buildings.

The dual conductors terminate with F-connectors for video and screw terminals for power. Sequential printing tracks usage accurately. Installers benefit from low-friction surface in conduits. Grounding the shield prevents hum in video lines.

For installation best practices, visit BICSI.

Durability and Compliance Features

Pure copper center resists oxidation for consistent conductivity over years. Braid coverage blocks 99% of EMI from motors or radios. Flame retardant per UL 1666 for plenum alternatives. The cable survives 500+ flex cycles without integrity loss.

Moisture barriers in the dielectric prevent water ingress. Crush resistance reaches 300 psi for direct burial. Lifecycle exceeds 15 years in rated exposures. Certifications include RoHS for eco-compliance and ETL for safety.

Why Trust Novatech for Your Video Cabling Needs

At Novatech Technologies, we certify cables like the Hikvision RG59 Cable With Power 100M through signal sweep tests for purity. Our inventory spotlights integration and longevity for surveillance demands. We source from OEM partners to match exacting specs.

Spools arrive with batch traceability for accountability. Our technicians supply termination kits and torque values. Clients access demo videos for hybrid analog-digital transitions. We build ecosystems that evolve with security trends.

This cable unifies video and power runs efficiently. Pair it with HP Series 5 23.8-inch FHD Monitor for control displays. Our printers category aids report generation.

We offer field audits to verify signal quality post-install. Our passion secures every frame. Rely on us for vigilant connectivity.
